Nakamichi RX-202

Two Head Auto Reverse Stereo Cassette Deck (1982-93)

Description

The RX-202 transport features UDAR, Nakamichi's unique uni-directional auto-reverse mechanism, eliminating the azimuth error loss of conventional auto-reverse decks.

The music sensing circuit monitors playback and fast forwards through blank 'tail' to provide uninterrupted playback.

A dual master fader creates smooth 2 or 4 second fades at a touch.

The frequency response of the RX-202 rivals that of most 3-head decks thanks to a specially designed laminated Sendust record/play head.

Specifications

Type: auto reverse, 2-head, single compact cassette deck

Track System: 4-track, 2-channel stereo

Tape Speed: 4.8 cm/s

Heads: 1 x record/playback, 1 x erase

Motor: 1 x reel, 1 x capstan, 2 x mechanism

Tape Type: type I, CrO2, Metal

Noise Reduction: B, C

Frequency Response: 20Hz to 20kHz  (Metal tape)

Signal to Noise Ratio: 68dB  (dolby C)

Wow and Flutter: 0.06%

Total Harmonic Distortion: 1.0%

Input: 50mV (line)

Output: 0.5V (line)

Dimensions: 451 x 136 x 255mm

Weight: 9kg

Year: 1982

Price: GBP £600 (1990)
